Peter's ADF Collection (5/5)
Last Update: 23.01.2003

If it is not listed here - I don't have it !
But feel free to send me missing ADFs, they are always welcome !
Some files may have foreign (i.e. German) text !


Adapter-IDs from 0000 - 5FFF
Adapter-IDs from 6000 - 67FF
Adapter-IDs from 6800 - 6FFF
Adapter-IDs from 7000 - 7FFF
Adapter-IDs from 8000 - FFFF

The -Symbol indicates: there is a picture available.
Just click on it to see the image.
Attention: The images are on a different site !



  • @8002.ADF - AHEAD SYSTEMS INC., VGA ENHANCER-Z
  • @8002.ADF - SuperVGA/MC Display Adapter, Ver. 3.0
    For a similar card - rename to @8002.ADF !


  • @8007.ADF - Vermont Microsystems Page Manager 100
  • @8009.ADF - Vermont Microsystems COBRA /2
  • @800D.ADF - PIXELWORKS PS/2 Ultra Clipper Graphics Subsystem
  • @8010.ADF - Microeye 1C Video digitiser
  • @8015.ADF - ETAP NEFTIS/20 or ATRIS/20 A,B
  • @8016.ADF - ETAP NEFTIS/20 or ATRIS/20
  • @8023.ADF - SPEA - Flash 2
  • @8025.ADF - SPECTRA/2 Video-Board
  • @8027.ADF - ELSA XHR Alpha/2 Video-Board
  • @8028.ADF - VideoLogic DVA4000/MCA Adapter
  • @8029.ADF - Datagraph Pixelstar PS/2
  • @803B.ADF - SPEA - Flash 1
    SPEA - Flash 1

  • @803C.ADF - Rasterex (Int.) a.s, AK Graphics Board
  • @803F.ADF - RM High Resolution Monochrome Display Adaptor

  • @8044.ADF - Western Digital Imaging PRO MC Video Adapter
  • @8044.ADF - Paradise 8514/A Plus Video Adapter
    same card - other brand / rename to @8044.ADF !


  • @8048.ADF - Sigma Designs' L-VIEW for the PS/2
  • @805B.ADF - ELSA XHR Gemini Graphic Subsystem
    ELSA XHR Gemini Graphic Subsystem

  • @8066.ADF - Radius MultiView 24 MC
  • @8069.ADF - miroMAGIC Graficcontroller

  • @807F.ADF - MDSI / JURDA 17-Zoll Video Adapter
  • @807F.ADF - MICRO DISPLAY SYSTEMS Video Adapter
    similar adapter / rename to @807F.ADF


  • @8080.ADF - Control Systems Artist 10/16 VGA
    Control Systems Artist 10/16 VGA
    Control Systems Artist 10/16 old Version Baseboard
    Control Systems Artist 10/16 old Version Memory Board

  • @8088.ADF - ATI 8514/ULTRA
    ATI 8514/ULTRA

  • @8089.ADF - ATI GRAPHICS ULTRA MCA Video Acc.
    Version 2.2 / 10-02-94, VGA ENABLED
  • @808A.ADF - ATI GRAPHICS ULTRA MCA Video Acc.
    Version 2.2 / 10-02-94, VGA DISABLED


  • @8099.ADF - #9GX Microchannel Graphics Adapter
  • @809A.ADF - Number 9 GXI Graphic Coprocessor
    Number 9 GXI Graphic Coprocessor

  • @80A5.ADF - Cornerstone High Resolution Display
  • @80A5.ADF - Cornerstone DualPage Display
    similar card / rename to @80A5.ADF


  • @80A6.ADF - Cornerstone ImageAccel Display
    Cornerstone ImageAccel

  • @80A9.ADF - Intel ActionMedia(TM) Adapter
  • @80AE.ADF - Sigma Designs' L-VIEW PS/2 with VGA Emu.
  • @80AF.ADF - Sigma Design's PageView (VGA) for the PS/2
  • @80B3.ADF - IBM M-Motion Video Adapter
    IBM M-Motion Video Adapter

  • @80B7.ADF - Radius SVGA MultiView
    Radius SVGA MultiView
    Radius Drivers on FTP


  • @80C3.ADF - ARTIST XJS MC Graphic Adapter
  • @80C5.ADF - ARTIST 1000 MC Series
    ARTIST 1000 MC Series

  • @80C7.ADF - ARTIST 1000i MC Series
    ARTIST Drivers Website


  • @80CC.ADF - Microfield T8/2 High Res Graphics Controller
  • @80E6.ADF - RasterOps ColorBoard 1024MC
  • @80E8.ADF - Matrox MG-104/108-M Adapter
  • @80EC.ADF - Matrox MGA Video Adapter (V0.02)
  • @80EE.ADF - ILLUM-16/MC Video Graphics Board
  • @80F2.ADF - Tseng Labs ET4000 VGA Adapter
  • @80F6.ADF - RasterOps ColorBoard 1024MC
  • @80F8.ADF - Matrox PG2-1281 Hi-res Graphics Controller
    Matrox PG2-1281 - Base Card
    Matrox PG2-1281 - Memory / RAMDAC Card

  • @80FC.ADF - STB PowerGraph MC VGA Adapter
  • @80FD.ADF - STB MC/MVP ERGO VGA Adapter
  • @80FF.ADF - GalaGraph MERCURY/2 graphic board
  • @8128.ADF - SPEA - HiLite MCA


  • @812E.ADF - NCR 3350/3355 HPG Video Adapter (w/o ROM)
  • @817E.ADF - NCR 3350/3355 HPG Video Adapter (with ROM)
  • @8182.ADF - REPLY VIDEO ADAPTER
  • @81DF.ADF - HR Graphic Adapter INFO IGP64/MCA
  • @8202.ADF - AHEAD SYSTEMS INC., VGA ENHANCER-Z, Rev. A
  • @8207.ADF - ADEX ChromaGraph II
  • @8484.ADF - IBM 5080 Serial Link Adapter
  • @8DF0.ADF - IBM Image Adapter/A
  • @8DF1.ADF - IBM Image/A and Printer/Scanner Option
  • @8DF2.ADF - DSS and sub card 2
  • @8DF3.ADF - DSS and sub card 3
  • @8DF4.ADF - IBM Image Adapter/A 3MB
    IBM Image Adapter/A 3MB

  • @8DF5.ADF - IBM Image/A with Printer/Scanner Option
  • @8DF6.ADF - IBM Image-I Adapter/A


  • @8EE6.ADF - SGI Irisvision Adapter
    SGI Irisvision - Geometry Engine
    SGI Irisvision - Raster Video Engine
    SGI Irisvision - 24-bit Frame Buffer
    SGI Irisvision - Optional Z-Buffer

  • @8EF5.ADF - IBM PS/2 Bus Master Adapter/A for Ethernet
    This adapter is from the RS/6000 - and might
    not work in PS/2 systems - OEM card from 3COM

    IBM PS/2 Bus Master Adapter/A for Ethernet

  • @8EF7.ADF - ARTIC 960 ADD System Resource - ID = 8EF7
    Also refered to as: 8EF7h System Resource (ID = 8EF7)


  • @8EF8.ADF - Expansion Unit SCSI Controller
  • C8EF8.ADF - Init file for @8EF8

  • @8EFC.ADF - IBM PS/2 Fast/Wide SCSI Adapter
  • C8EFC.ADF - Init file for @8EFC.ADF
    IBM PS/2 Fast/Wide SCSI Adapter

  • @8EFD.ADF - SCSI Cached Disk/Diskette Controller - ID = 8EFD
    Also refered to as: 8EFD IBM 7568 Gearbox Model 800 Cached SCSI Adapter


  • @8EFE.ADF - IBM PS/2 SCSI Adapter
  • C8EFE.ADF - Init file for @8EFE.ADF
    IBM PS/2 SCSI Adapter - Old, long
    IBM PS/2 SCSI Adapter - New, short

  • @8EFF.ADF - IBM PS/2 SCSI Adapter w/Cache
  • C8EFF.ADF - Init file for @8EFF.ADF
    IBM PS/2 SCSI Adapter w/Cache - Earlier
    IBM PS/2 SCSI Adapter w/Cache - Later

  • @8F6A.ADF - IBM Ethernet Quad-B2 PeerMaster
  • C8F6A.ADF - Init File for @8F6A.ADF

  • @8F6C.ADF - DAC960M RAID Adapter

  • @8F6D.ADF - IBM Ethernet Quad-BT PeerMaster
  • C8F6D.ADF - Init File for @8F6D.ADF

  • @8F70.ADF - IBM RIC Portmaster Adapter/A
  • C8F70.ADF - Init file for @8F70.ADF
    IBM RIC Portmaster - Base Card
    IBM RIC Portmaster - 8 x RS232 Daughter Card

  • @8F82.ADF - IBM SCSI-2 F/W Streaming-RAID /A'Cheetah'
    IBM SCSI-2 F/W Streaming-RAID

  • @8F93.ADF - IBM PS/2 ServerGuard
    IBM PS/2 ServerGuard

  • @8F9C.ADF - IBM FDDI Fiber / Copper MC Base Card /MC
    IBM FDDI Copper MC Base Card
    IBM FDDI Copper Daughter Board

  • @8F9E.ADF - IBM S/390 Microprocessor Complex (P/390)
  • @8FA0.ADF - IBM LANStreamer MC 32 Adapter
    IBM LANStreamer MC 32 Adapter

  • @8FA2.ADF - IBM Auto LANStreamer MC 32 Adapter
    IBM Auto LANStreamer MC 32 Adapter

  • @8FA4.ADF - IBM LANStreamer MC 16 Adapter
    IBM LANStreamer MC 16 Adapter

  • @8FA8.ADF - IBM EtherStreamer MC32 Adapter
    IBM EtherStreamer MC32 Adapter

  • @8FAA.ADF - IBM Dual LANStreamer MC 32 Adapter
    IBM Dual LANStreamer MC 32 Adapter

  • @8FAB.ADF - IBM Dual EtherStreamer MC32 Adapter
  • @8FBB.ADF - IBM RAID Controller 'Passplay'
    IBM RAID Controller

  • @8FC8.ADF - IBM TR-Net 16/4 Busmaster Server Adapter
    IBM TR-Net 16/4 Busmaster Server Adapter

  • @8FD6.ADF - IBM Audiovation Adapter
    IBM Audiovation Adapter

  • @8FD7.ADF - IBM PS/2 W4 Adapter

  • @8FDA.ADF - IBM XGA-2 Display Adapter
  • C8FDA.ADF - Init file for @8FDA.ADF
    IBM XGA-2 Display Adapter

  • @8FDB.ADF - IBM XGA Display Adapter
  • C8FDB.ADF - Init file for @8FDB.ADF
    IBM XGA Display Adapter

  • @8FE0.ADF - IBM WaveRunner ISDN Digital Modem
    IBM WaveRunner ISDN Digital Modem

  • @8FEB.ADF - IBM MWave WindSurfer-MCA Communications Ad.
    IBM MWave WindSurfer-MCA

  • @8FEC.ADF - IBM ARTIC960 Co-Processor Platform Adapter
  • C8FEC.ADF - Init file for @8FEC.ADF

  • @8FFB.ADF - IBM Gearbox Model 800 486 Processor Card
    Also referenced as: 8FFB Processor ID = 8FFB
  • @8FFF.ADF - IBM Gearbox Model 800 Processor Card
    Also referenced as: 8FFF Processor ID = 8FFF


  • @90EE.ADF - IBM NI-SVGA Adapter
    IBM NI-SVGA Adapter

  • @917B.ADF - SVGA Adapter
  • @917D.ADF - Flat Panel Touch Adapter
  • @917E.ADF - Flat Panel Display Adapter

  • @A980.ADF - Intel ActionMedia(TM) Adapter

  • @CC06.ADF - SPECTRA/2 Video-Board
  • @CCEC.ADF - CORnet LAN Interface Adapter

  • @D7D7.ADF - ZOT-N200A Microchannel ARCNET Interface
  • @DBDB.ADF - ZOT-N200A Microchannel ARCNET Interface
  • @DDCD.ADF - IBM V.32 Modem/A
  • @DDDD.ADF - ZOT-N200A Microchannel ARCNET Interface

  • @DDFF.ADF - IBM ESDI Fixed Disk Controller
    ADP CDDFF.ADF not required / rename to @DDFF.ADF
  • @DDFF.ADF - IBM ESDI Fixed Disk Controller
  • CDDFF.ADF - Init file for @DDFF.ADF
    IBM ESDI Fixed Disk Controller
    WD-1007 ESDI Fixed Disk Controller

  • @DEDE.ADF - ZOT-N200A Microchannel ARCNET Interface
  • @DEFF.ADF - IBM Multi-Protocol Adapter
    IBM Multi-Protocol Adapter

  • @DF7F.ADF - IBM 3363 Optical Disk
    IBM 3363 Optical Disk

  • @DF9F.ADF - IBM Integrated Fixed Disk and Controller
  • @DF9F.ADF - IBM 50-021 to 50Z HD-upgrade Controller
    rename to @DF9F.ADF


  • @DFAF.ADF - IBM 4250 Printer Adapter/A
  • @DFBF.ADF - IBM 6157 Tape Adapter Card
    IBM 6157 Tape Adapter Card

  • @DFDF.ADF - ZOT-N200A Microchannel ARCNET Interface
  • @DFE8.ADF - Integrated Hard Disk and Controller
  • @DFF4.ADF - IBM Wireless LAN Adapter
    IBM Wireless LAN Adapter (ISA/MCA Turnover)

  • @DFFA.ADF - IBM 5.25-inch Diskette Drive Adapter
    IBM 5.25-inch Diskette Drive Adapter

  • @DFFC.ADF - IBM InfoWindow GPIB2 Card

  • @DFFD.ADF - IBM ST506 Fixed Disk Adapter
  • @DFFD.ADF - NCR ST506 Fixed Disk Adapter
    Phoenix version / rename to @DFFD.ADF

    IBM ST506 Fixed Disk Adapter
    IBM ST506 Fixed Disk Adapter - 50-021 Version

  • @E000.ADF - IBM Token-Ring Network Adapter
    IBM Token-Ring Network Adapter - Old, long
    CIBM Token-Ring Network Adapter - Later, short

  • @E000.ADF - D-Link DT-300 Token-Ring Adapter
    Similar to IBM TR 16/4-Adapter / rename to @E000.ADF


  • @E001.ADF - IBM Token-Ring Network 16/4 Adapter/A
  • @E001.ADF - IBM Auto 16/4 Token-Ring MC (more features)
    WARNING This file might not be compatible to all older
    IBM TR-Adapters with Card-ID E001 and 'Tropic'-chipset !
    In case of doubt use the standard E001-file from above.



    100% IBM-compatible 'Tropic' Adapter, rename ADFs to @E001.ADF :


  • @E001.ADF - COMPEX ReadyLINK(R) TRN 16/4 Adapter
  • @E001.ADF - Hypertec HyperRing MC 16/4
  • @E001.ADF - KINGSTON TOKENRX 16/4 TOKEN RING ADAPTER
  • @E001.ADF - MADGE 'STRAIGHT BLUE' 16/4 TR ADAPTER


    IBM TR 16/4 - Old, long version
    IBM TR 16/4 - Later, short version
    Madge 'Straight Blue' TR 16/4 Version
    IBM Auto TR 16/4 Adapter
    Hypertec TR 16/4 Adapter

  • @E00F.ADF - D-LINK Token-Ring Network Adapter
  • @E014.ADF - IBM S/370 Channel Emulator Adapter/A
  • @E016.ADF - IBM 300/1200/2400 Internal Modem/A
  • @E04E.ADF - IBM 3117 High Speed Adapter/A
  • @E04F.ADF - IBM 3119 Scanner Adapter
    IBM 3119 Scanner Adapter

  • @E1FF.ADF - IBM 3270 Connection Version B
    IBM 3270 Connection Version B

  • @E7FF.ADF - IBM 3270 Connection Version A
  • @E7FF.ADF - Memorex Telex 1472/Uni 3270 MCA Coax Adapter
    compatible 3270-adapter / rename to @E7FF.ADF

    IBM 3270 Connection - Long, later version
    IBM 3270 Connection - Long, earlier version
    IBM 3270 Connection - Attachmate Version

  • @E8FC.ADF - IBM Infrared Wireless LAN Adapter /A

  • @E9FE.ADF - IBM Expansion Unit Model 001
  • @E9FF.ADF - IBM Expansion Unit Model 002

  • @ECFF.ADF - IBM 5250 Emulation Adapter/A
  • @EDFF.ADF - IBM Internal Modem
  • @EEBB.ADF - MIRACOM OEM MODEM
  • @EEBF.ADF - IBM 4693 Store Loop Adapter/A
  • @EED7.ADF - DEKKO2 DUT CARD
  • @EEE7.ADF - IBM Serial Port No. 2
  • @EEFF.ADF - IBM Dual Async Adapter
    IBM Dual Async Adapter

  • @EF7F.ADF - IBM Display Adapter 8514/A
  • CEF7F.ADF - Init file for @EF7F.ADF
    IBM Display Adapter 8514/A - Base Card
    IBM Display Adapter 8514/A- 512K Memory
    IBM Display Adapter 8514/A - 1MB Memory

  • @EF7F.ADF - EIZO AC41/AC51 Graphics Display Ad.
    WARNING ! Double ID, rename to @EF7F.ADF
  • @EF7F.ADF - ELSA Winner/2
    WARNING ! Double ID, rename to @EF7F.ADF

    ELSA Winner/2

  • @EFB0.ADF - IBM ISDN/2 Co-Processor Model 2
  • @EFBF.ADF - IBM InfoWindow VGA Control Card
  • @EFCB.ADF - IBM POS Expansion Adapter
  • @EFCD.ADF - IBM Wide Area Connector
    IBM Wide Area Connector

  • @EFCF.ADF - IBM Store Loop Adapter
  • @EFD4.ADF - IBM PS/2 Adapter/A for Ethernet Networks
  • @EFD5.ADF - IBM PS/2 Adapter/A for Ethernet Networks
  • @EFD9.ADF - IBM Font ROM
  • @EFDA.ADF - IBM PCMCIA Adapter
    IBM PCMCIA Adapter

  • @EFDC.ADF - IBM ActionMedia (TM) II Display Adapter
  • @EFDC.ADF - Intel DS2 Adapter
    alternatively - same card / rename to @EFDC.ADF

    IBM ActionMedia (TM) II Display Adapter

  • @EFDF.ADF - ASTER/2 ArcNet controller
  • @EFE0.ADF - IBM ISDN Interface Co-Processor /2
  • @EFE5.ADF - IBM PS/2 Adapter/A for Ethernet Networks
    IBM PS/2 Adapter/A for Ethernet Networks

  • @EFEF.ADF - IBM PC Network Adapter
    IBM PC Network Baseband Adapter
    IBM PC Network Broadband Adapter

  • @EFF0.ADF - IBM RIC Multiport /2 or IBM X.25 CoPro
    IBM X.25 CoProzessor Adapter
    IBM RIC Multiport/2
    Multiport Interface Board (2 Ser.)

  • @EFF5.ADF - Ungermann-Bass NICps/2 Ethernet LAN Adapter
  • @EFF6.ADF - IBM Personal Pageprinter Adapter
    IBM Personal Pageprinter Adapter - Base Card
    IBM Personal Pageprinter Adapter - Memory Card

  • @EFFD.ADF - IBM VGA Adapter

  • @F04F.ADF - IBM 3117 Scanner Adapter/A

  • @F7F7.ADF - IBM 2-8MB 286/386SX Memory Expansion Option
  • @194.PEP -
    IBM 2-8MB 286/386SX Memory

  • @F7FE.ADF - IBM Memory Expansion Card 0-8 MB XMA
  • @085.PEP -

  • @FA74.ADF - IBM 370 Technical Workstation

  • @FAFF.ADF - IBM 0-6 MB 386 Memory Expansion Adapter
  • CFAFF.ADF - Init file for @FAFF.ADF
    IBM 0-6 MB 386 Memory

  • @FCF0.ADF - Serial / Parallel Adapter
    several brands

    Serial / Parallel Adapter

  • @FCF1.ADF - VISION LOGIC DUAL SERIAL ADAPTER

  • @FCFF.ADF - IBM 0-8MB 386 Memory Expansion Adapter
  • CFCFF.ADF - Init file for @FCFF.ADF
    IBM 0-8MB 386 Memory

  • @FDDE.ADF - IBM Enh. 80386 Memory Exp. Adapter w/ROM
  • CFDDE.ADF - Init file for @FDDE.ADF
    IBM Enh. 80386 Memory Exp. Adapter w/ROM

  • @FDDF.ADF - IBM Enh. 80386 Memory Exp. Adapter
  • CFDDF.ADF - Init file for @FDDF.ADF - required !
  • IFDDF.ADF - Init file for @FDDF.ADF - required !
  • @FDDF.ADF - IBM Enh. 80386 Memory Exp. Adapter
    alternate file / more settings / rename to @FDDF.ADF

    IBM Enh. 80386 Memory - Old, downlevel card
    IBM Enh. 80386 Memory - Last Revision

  • @FEFE.ADF - IBM 2 MB 16-bit Memory Adapter
  • CFEFE.ADF - Init file for @FEFE.ADF
    IBM 2 MB 16-bit Memory
    Multi I/O card (unknown Mfg.)
    Attention: Double ID for different cards !


  • @FFDE.ADF - IBM 16MB Memory Expansion Adapter - ID = FFDE
  • CFFDE.ADF - Init file for @FFDE.ADF

  • @FFE0.ADF - IBM LAN Adapter/A for Ethernet
    IBM LAN Adapter/A for Ethernet - Old
    IBM LAN Adapter/A for Ethernet - New

  • @FFE2.ADF - 4693 Device Channel
  • @FFF8.ADF - IBM 36/38 Workstation Adapter
    IBM 36/38 Workstation Adapter


Go To MCA-Index
Previous
Visit my Homepage

© 1999 by Peter H. Wendt / pw-software productions
