Peter's ADF Collection (2/5)
Last Update: 23.01.2003

If it is not listed here - I don't have it !
But feel free to send me missing ADFs, they are always welcome !
Some files may have foreign (i.e. German) text !


Adapter-IDs from 0000 - 5FFF
Adapter-IDs from 6000 - 67FF
Adapter-IDs from 6800 - 6FFF
Adapter-IDs from 7000 - 7FFF
Adapter-IDs from 8000 - FFFF

The -Symbol indicates: there is a picture available.
Just click on it to see the image.
Attention: The images are on a different site !



  • @6000.ADF - Tiara LanCard/EII Ethernet/Cheapernet Adapter
    Tiara LanCard/EII

  • @6001.ADF - Tiara LanCard/E*MC TWISTED PAIR Adapter
  • @6011.ADF - Computer Logics Ltd. - MicroLogic II Adapter
  • @6014.ADF - ARCNET-PS110
    Netware or SMC

    ARCNET-PS110

  • @6016.ADF - SMC3016/MC Ethernet Card
  • @6018.ADF - Gateway Communications G/Ethernet Controller
    Gateway Communications G/Ethernet Controller

  • @601C.ADF - Multi-Tech Systems MT224PS/ES
  • @601F.ADF - Hewlett-Packard Scanner Interface
    Hewlett-Packard Scanner Interface

  • @6020.ADF - Cumulus CuRAM-16 Plus 2 MB Memory Multif. Ad.
  • @6021.ADF - Cumulus CuRAM-16 Plus 4 MB Memory Multif. Ad.
  • @6022.ADF - Cumulus CuRAM-16 Plus 6 MB Memory Multif. Ad.
  • @6023.ADF - Cumulus CuRAM-16 Plus 8 MB Memory Multif. Ad.
  • @6024.ADF - Cumulus CuRAM-16 Plus 10MB Memory Multif. Ad.
  • @6025.ADF - Cumulus CuRAM-16 Plus 12MB Memory Multif. Ad.
    Cumulus CuRAM-16 Plus Memory Multif. Ad.

  • @6029.ADF - MetraByte UCDAS-8PGA Data Acquisition Board
  • @602F.ADF - ARCMASTER Microchannel/Arcnet Interface
  • @6038.ADF - DEST Corp. Scanner Controller
  • @6040.ADF - Intel 2400B Modem 2
  • @6042.ADF - 3Com EtherLink/MC Ethernet Adapter
    3Com EtherLink/MC Later Version
    3Com EtherLink/MC Earlier Version

  • @6054.ADF - Kronos RS-485 Comm/Key Adapter 6600133-001
  • @605F.ADF - Tiara LANcard/A-II ARCnet Adapter

  • @6060.ADF - IDEAcomm 5251 4 LU Card - long card
  • @6060.ADF - IDEAcomm 5251 7 LU Card - short card
    alternate file / rename file to @6060.ADF)
  • @6060.ADF - Trisystems TRI-010-1 Local 5250 Adapter
    alternate name / rename file to @6060.ADF

    IDEAcomm 5251 7 LU Card Short Version

  • @6061.ADF - 3270 Local Communication Card
  • @6065.ADF - INS SDLC Adapter
  • @6078.ADF - COMTROL HOSTESS/MC Eight Port Serial Adapter
  • @608D.ADF - Hypertec Hyperam MC 32/16 SIMM
  • @608E.ADF - Hypertec Hyperam MC 32/16 MF
  • @608F.ADF - Hypertec HYPERPORT


    More infos at Hypertec


  • @6091.ADF - Stallion Tech. ONboard2 Terminal System
  • @6094.ADF - REPLY AT IDE Drive Adapter
  • @6088.ADF - MetraByte UCCTM-05 Counter/Timer Board
  • @609E.ADF - MICROTEK MS-PS/2 Interface Adapter
  • @60A1.ADF - Software Dynamics, Inc. MPCC/2
  • @60AC.ADF - MICROTEK MS-PS/2 Interface Adapter
  • @60B7.ADF - Advanced Vision Research MegaBuffer/2
  • @60C2.ADF - Boca Research Dual Async/Parallel Adapter
  • @60C9.ADF - BOCA Bidirectional Parallel Adapter
    sold under several brands

    BOCA Bidirectional Parallel Adapter

  • @60D0.ADF - Quadram JT Fax PS/Q
  • @60E5.ADF - Boca Research Dual Async/Parallel Adapter 2
    Boca Research Dual Async/Parallel Adapter 2

  • @60E9.ADF - Fast SCSI-2 Adapter/A
    Future Domain Fast SCSI-2 Adapter MCS-700
    IBM Fast SCSI-2 Adapter/A

  • @60ED.ADF - MDCB/2 & FDCB/2 Disc Coprocessor Boards
  • @60FC.ADF - AMS RS232CL or RS422/485-IO MC Ad. Rev B

  • @6104.ADF - AMS Multiport Adapter: 2 Ser./ 1 Par. Ports
  • @6104.ADF - AMS XPRESS-144 MC (Rev C)
    later cards / rename to @6104.ADF

    AMS Multiport Adapter: 2 Ser./ 1 Par. Ports

  • @610F.ADF - AMS IOSIX-6 Adapter
  • @611A.ADF - Banyan Systems ICA/mC Intelligent Communications Adapter
  • @611B.ADF - LaserMaster Controller
  • @611F.ADF - NetWorth, Inc. - EtherNext/MC Network Adapter
  • @6127.ADF - Future Domain SCSI Adapter MCS600/700
    Future Domain SCSI Adapter MCS-700

  • @613A.ADF - Dialogic D/81-MC, D/41-MC
  • @613D.ADF - Rabbit RB75 Remote Communications Processor
  • @613F.ADF - SONIC Model 50,60,70,80 Demo Board
  • @6147.ADF - Novell Micro Channel Compatible Key Card
    Novell Micro Channel Compatible Key Card

  • @6149.ADF - Micro Channel Key Card Extender
  • @6150.ADF - Novell NL/2 MCA LocalTalk Adapter
  • @6157.ADF - NOVELL REMOTE III ADAPTER
  • @6162.ADF - COMTROL HOSTESS 550/MC 16 Port Serial Ad.
  • @6163.ADF - DIGI Sync/570i
  • @6167.ADF - S-S Technologies 5136-SD-MCA V2.0
  • @6169.ADF - Gravis Eliminator (MCA) Game Card
  • @616A.ADF - NSS WNIC/MCA
  • @616E.ADF - Computone PS6
  • @616F.ADF - AMS IOSIX-1 Adapter
  • @6179.ADF - COMTROL HOSTESS 550/MC 8 Port Serial Adapter
  • @617B.ADF - Wall Data Datagate/Coax
  • @617E.ADF - Computone PS8 8-port Controller
    sold under several brands - functionally identical

    Computone PS8 8-port Controller

  • @617F.ADF - AMS IOSIX-2 Adapter
  • @6180.ADF - Lava Async/2 Adapter
  • @6181.ADF - Lava Parallel Link
  • @6182.ADF - Lava Link 2400/A Adapter
  • @6183.ADF - Lava Link 422 Adapter

  • @6184.ADF - Lava 8 Megabyte Extended Memory Adapter
  • @6184.ADF - Lava 4 Megabyte Extended Memory Adapter
    Older card / rename to @6184.ADF

    The required Init-File is still missing for both cards !


  • @6185.ADF - Lava Arclink/A
  • @61AF.ADF - AMS IOSIX-9 Adapter
  • @61B4.ADF - CAERE TYPIST INTERFACE
    CAERE TYPIST INTERFACE

  • @61BF.ADF - Intel SatisFAXtion Adapter
    Intel SatisFAXtion Adapter

  • @61C7.ADF - AVM ISDN Controller B1-MCA
    AVM ISDN Controller B1-MCA

  • @61C8.ADF - SMC/WD EtherCard PLUS Elite/A (8013EP/A)
    SMC/WD EtherCard PLUS Elite/A (8013EP/A)

  • @61C9.ADF - SMC/WD EtherCard PLUS Elite 10T/A (8013WP/A)
    SMC/WD EtherCard PLUS Elite 10T/A (8013WP/A)

  • @61CB.ADF - Smile Target Adapter for IBM PS/2
  • @61DF.ADF - ATTACHMATE - Asynchronous SNA Adapter/2
  • @61E0.ADF - NCR Neural Network Board
  • @61FD.ADF - Computone PSCC Cluster Controller
  • @6201.ADF - QUADPORT PS/Q I/O Adapter R2 9087
  • @6203.ADF - QUADPORT PS/Q I/O Adapter R2 9087
  • @6205.ADF - Excelan EXOS 215T Intelligent Ethernet Ad.
  • @6213.ADF - Custom Computer Systems IDE Fixed Disk Ad. C1000
  • @621C.ADF - NCR 16 Port Serial Controller/MC
  • @621F.ADF - Hewlett-Packard ScanJet II Interface Adapter
  • @6220.ADF - ACCTON Micro Channel EtherPair/EtherCoax adapter
  • @6222.ADF - The NCI 4700 PCI/MC
  • @6226.ADF - Asante Technologies EtherPaC Ethernet Adapter
  • @6256.ADF - Xionics Lightning Image Accelerator
  • @6258.ADF - Alert Technology Serial Adaptor
    Alert Technology Serial Adaptor

  • @6259.ADF - Alert Technology Printer Adaptor
    Alert Technology Printer Adaptor

  • @6262.ADF - p1800 ProNET-10 Network Adapter for PS/2

  • @6263.ADF - Arco Electronics AC-1070 IDE Controller
    supports CD-ROM
  • @6263.ADF - Arco Electronics AC-1070 IDE Controller
    Different brands: i.e. from CMS Enhancements

    Arco Electronics AC-1070 IDE Controller
    CMS Enhancements IDE Controller (ARCO OEM)

  • @626B.ADF - Apricot AdLOC(tm) Security Card
  • @626F.ADF - INTERCOPE ISDN Communication Server 1
  • @627A.ADF - Kingston Technology Data Master
    Kingston Technology Data Master

  • @627C.ADF - 3Com 3C529 Network Adapter
    3Com 3C529 Network Adapter

  • @627D.ADF - 3Com 3C529-TP Network Adapter
    3Com 3C529-TP Network Adapter

  • @628B.ADF - Intel EtherExpress(tm) MC Network Adapter
    Intel EtherExpress(tm) MC Network Adapter

  • @628D.ADF - Digital Ethernet Micro Channel Adapter
  • @628D.ADF - Digital EtherWORKS MC Adapter DE210/DE212
    Later Version. Rename to @628D.ADF


  • @629F.ADF - Reply AT IDE Drive Adapter
  • @62A6.ADF - Dialogic TTS/80-MC, TTS/40-MC
  • @62A9.ADF - NCR Recognition Accelerator Board 10MB
  • @62AC.ADF - Logitech ScanMan256 Adapter
  • @62AF.ADF - BocaBoard Micro Channel 4 Port Serial Ad.
  • @62B0.ADF - BocaBoard Micro Channel 16 Port Serial Ad.
  • @62B6.ADF - Arco Electronics AC-1079 SLIM Drive Adapter
  • @62BF.ADF - ATTACHMATE - Adv. Function SDLC Adapter/2

  • @62E9.ADF - PM14400 PS/2 Internal Modem
  • @62E9.ADF - Kingston 14400 PS/2 Internal Modem
    alternate name / rename to @62E9.ADF

    PM 14400 PS/2 Internal Modem

  • @62F0.ADF - Plexus AIP2 Card
  • @62F9.ADF - Stallion Technologies EasyConnection 8/32
  • @6303.ADF - Meinberg Funkuhr PS31
  • @630A.ADF - Dialogic VR/81-MC, VR/41-MC
  • @631F.ADF - Hewlett-Packard ScanJet II Interface Adapter
  • @6321.ADF - The MicroPort 2
  • @6322.ADF - The MicroPort P
  • @6323.ADF - BOCport Par/Ser (german text)
    BOCport Par/Ser

  • @6336.ADF - Eicon.Diehl DIVA MCA Adapter
  • @6343.ADF - LANtastic (tm) Artisoft Inc. 2Mbps Net Ad.
    LANtastic (tm) Artisoft Inc. 2Mbps Net Ad.

  • @6358.ADF - COMTROL RocketPort 16/MC Serial Adapter
  • @6359.ADF - COMTROL RocketPort 8/MC Serial Adapter
  • @635A.ADF - COMTROL RocketPort 32/MC Serial Adapter

  • @6361.ADF - Arnet Co. Smartport/2 Communications Adapter
  • @6361.ADF - Digi SmartPort/2 Communications Adapter
    same card - rename to @6361.ADF


  • @6378.ADF - Digi SyncPort/1
  • @6384.ADF - Megaport serial Adapter
  • @6386.ADF - Megaplex PS/2 Adapter
  • @6388.ADF - Equinox SST-64M Controller (Remote Access)
  • @6389.ADF - Equinox SST-128M Controller (Remote Access)
  • @638A.ADF - Equinox SST Multiport Controller (Remote Access)
  • @63B3.ADF - CH Products GameCard III-Automatic
    CH Products GameCard III-Automatic

  • @63CA.ADF - Hewlett Packard StarLAN-10 Adapter Rev 1.1
    Also referenced as : Hewlett Packard HP Ethertwist/MC)

    Hewlett Packard StarLAN-10 Adapter

  • @63FF.ADF - Local Twinax Adapter
  • @6405.ADF - IDE Controller for Model 60 & 80
  • @6406.ADF - AT&T GIS 8 Port Serial Controller/MC
  • @6407.ADF - Avanstar 100 M
  • @6410.ADF - ATI AT1720T
  • @6413.ADF - ATI AT1720BT
  • @6416.ADF - ATI AT1720AT
  • @6419.ADF - ATI AT-1720FT
  • @6440.ADF - NCR MCA IN-HOUSE DLC COMMUNICATIONS ADAPTER
  • @6446.ADF - 3Com EtherLink/MC Ethernet Adapter
  • @6447.ADF - Olicom Ethernet MCA 10/100 Adapter
  • @647C.ADF - COMTROL HOSTESS/MC 4 Port Serial Ad.
  • @64B6.ADF - Thomas-Conrad ARC-CARD/MC
  • @64B7.ADF - Thomas-Conrad TCNS/MC
  • @6508.ADF - PDIuC508 Microchannel ARCNET Interface
    PDIuC508 Microchannel ARCNET Interface

  • @651B.ADF - Racore Token-Ring Adapter
  • @651E.ADF - Racore LANpac II for the IBM PS/2
  • @655B.ADF - Wang MC Local Office Connection (MCLOC)
  • @657D.ADF - COMTROL HOSTESS 550/MC 4 Port Serial Ad.
  • @6612.ADF - Evercom 24/2 Modem
  • @6674.ADF - DayStar LocalTalk/MCA AppleTalk Adapter
  • @6769.ADF - Hardlock on Card
  • @677F.ADF - ATTACHMATE - Advanced 3270 Adapter/2
    ATTACHMATE - Advanced 3270 Adapter/2


    (The following adapters from ROALAN or NEOTECH are functionally identical - Same card - different brand)


  • @6780.ADF - ROALAN FOUR CHANNEL SERIAL ADAPTER
  • @6781.ADF - ROALAN SERIAL ADAPTER
  • @6782.ADF - ROALAN PARALLEL ADAPTER
  • @6783.ADF - ROALAN SERIAL/PARALLEL ADAPTER
  • @6784.ADF - ROALAN DUAL RS-422/RS-485 SERIAL ADAPTER
  • @6785.ADF - NeoTecH S-485, RS-422 or -485 Serial Ad.
  • @6786.ADF - ROALAN TWO CHANNEL PARALLEL ADAPTER
  • @6787.ADF - ROALAN MS/4A, FOUR CHANNEL SERIAL ADAPTER
  • @6788.ADF - ROALAN MS/4B, FOUR CHANNEL SERIAL ADAPTER
  • @6789.ADF - ROALAN MS/4C, FOUR CHANNEL SERIAL ADAPTER
  • @678B.ADF - NeoTecH Dual RS-232 Async. Adapter
    NeoTecH Dual RS-232 Async. Adapter

  • @678C.ADF - NeoTecH Dual RS-232 Async. Adapter, S2M100
  • @678D.ADF - NeoTecH MSP/4, 4 channel s. + p. adapter
  • @678F.ADF - BBS GPIB-3000
  • @6791.ADF - NeoTecH Single RS-232 Async. Adapter, SM110
  • @6792.ADF - NeoTecH 2S/1P Adapter, SPM121 / SPM321
  • @6795.ADF - NeoTecH Single RS-422/485 Async., S1M200
  • @6796.ADF - NeoTecH Single Bidi Parallel Adapter, PM101
  • @6797.ADF - NeoTecH Dual Bidi Parallel Adapter, PM102
  • @67B0.ADF - LANtastic(R) NodeRunner 2000M/TC AE-2 MC Eth.
  • @67E1.ADF - NCR 8 Port Serial Controller/MC
  • @67E7.ADF - KRAFT G/S+ Adapter Card
    KRAFT G/S+ Adapter Card

  • @67F0.ADF - PGS LS300/LS300F Scanner Adapter
  • @67FD.ADF - Control Systems Artist 12 MC
  • @67FF.ADF - Formwriter Adapter/Print Controller


Go To MCA-Index
Next
Previous
Visit my Homepage

© 1999 by Peter H. Wendt / pw-software productions
